TST_FUxF-A-C-F_Montageanleitung_EN_15
15 Standards and directives
Machinery Directive:
2006/42/EC
➔ Device complies with Annex IV categories of machinery -
Section 21 "logic unit for safety functions"
EN ISO 13849-1:2015
Safety of machinery – safety-related parts of control systems –
part 1: General design principles
• Category: 2
• Performance Level (PL): d
• Safe functions:
o Endpoint detection
o Contacting edge evaluation (8,2/1,2 kΩ or optical)
o Photo eye incl. pull-in protection (comp. EN 12453
table 1: type D or type E with test)
o Slip door switch
o Slack rope switch
o Plug-in module TST SURAx
o Wireless safety system TST FSx
EN 62061:2005 + Cor.:2010 + A1:2013 + A2:2015
Safety of machinery - Functional safety of safety-related
electrical, electronic and programmable electronic control
systems (IEC 62061:2005)
• Safety integrity levels (SIL): 1
Low-Voltage Directive:
2014/35/EU
EN 60335-1:2012 / AC:2014 + A13:2017
Safety of electrical appliances for household and similar
use/Part 1 general requirements
• Type: stationary motor-driven machines
• Protection class 1
60335-2-103:2015
Safety of household and similar electrical appliances - Part2 -
103: Special requirements for drives for industrial doors, doors
and windows
EMC Directive:
2014/30/EU
Electromagnetic compatibility – basic technical standards:
• EN 61000-6-1:2007 interference immunity, living area
• EN 61000-6-2:2005 / AC:2005 interference immunity,
industrial area
• EN 61000-6-3:2007 / A1:2011 / AC:2012 Electromagnetic
radiation, living area
• EN 61000-6-4:2007 / A1:2011 Electromagnetic radiation,
industrial area
Applied national
specifications regarding
the above directives:
EN 12453 / EN 2017
Safety in use of power operated doors - Requirements
• Chapter 5.2 Drive Systems and Power Supply
