Braking resistor load
Integrated braking resistor
Max. 1.5 kW for max. 0.5 seconds
Repetition rate > 20 seconds
NOTE:
Electronic monitoring!
Thermal breaking point in overload!
The heatsink / brake
resistor on the back of the
housing can reach
temperatures up to 85° C. In
case of failure this may
briefly reach 280 ° C (<5
min.)!
Temperature range
Operation - board set
without housing:
Operation in the housing:
Storage:
Surrounding air temperature
-20...+65 °C
-20 ... +50 °C
Maximum 40 °C in steel and stainless steel housing!
-25...+70 °C / +50 °C
Observe the ventilation around the housing and the self-heating
inside the housing!
Before selecting the installation site, observe the requirements
in the installation instructions (see chapter Installation of the
controller)!
Temperature-dependent reduction in the duty cycle of the drive
note (s. "Drive output")
Device mobility
Stationary
Device type
Motor type. External motor is not part of the delivery from FEIG
ELECTRONIC GMBH.
Protection type
IP 65
In plastic, steel and stainless steel housings with closed cable
glands.
Tighten the screw on the frame near the motor connection!
Board variants meet IP 00.
Protection class:
Protection class I
Weight
approx. 5 kg (plastic housing)
max. 24 kg (steel housing 600x600 including controller)
Height
< 2000 m
Standards & directives
For details see chapter 15
Machinery Directive
Europe, type examination
Low-Voltage Directive
Europe (special versions for the American market with UL
certification)
EMC Directive
Europe
RoHS/WEEE/REACH
Europe
