TST_FUxF-A-C-F_Montageanleitung_EN_15
5.3 Safety edge on the integrated evaluation
Various types of safety edges can be connected, for example:
• Electrical safety edge with 1.2 kΩ or 8.2 kΩ terminating resistor.
• Dynamical optical system
If one of these types of safety edges is connected when the door controller is switched
on it will be recognized automatically.
If no safety edge is connected, automatic closing of the door is not possible.
Use of additional types of safety edges is possible. Please contact the door manufacturer in this
respect.
For the connection of the safety edge to a TST FU3F we recommend to place a split
ferrite (black, Würht Number: 74271722S) around the wires of the safety edge (terminal
43 – 45) as close as possible to the door controller around the complete motor cable.
The black split ferrite is not included in the scope of delivery!
