TST
Assembly instructions
FUF2 / FU3F-A/-C/-F
FEIG ELECTRONIC GmbH
Page 102 of 114
TST_FUxF-A-C-F_Montageanleitung_EN_15
Status messages during calibration
7-Segment display
Real text display
Description
E.i.E.c.:
Zur Zupos. → ↕
Übernahme mit Æ
calibration of the lower limit
position requested (in deadman
travel)
E.i.E.o.:
Zur Aufpos. → ↑
Übernahme mit Æ
calibration of the lower limit
position requested (in deadman
travel)
E.i.E.1
Zur Zwischenp.→↕
calibration of intermediate position
E1 (in deadman travel)
Pos:
null
/VTM_Torsteuerungen/Allgmeine Meldungen/Anzeige: 7-Segment + Klartext/Statusmeldungen während
Status messages during dead man movement
7-Segment display
Real text display
Description
Hd.cL
--
Deadman closing (membrane
key: CLOSE)
Hd.oP
--
Deadman opening (membrane
key: OPEN)
Hd.Eu
Deadman close
Lower limit position reached, no
further deadman closing possible
Hd.Eo
Deadman open
Upper limit position reached, no
further deadman opening possible
Hd.Ao
Outside open
Outside of permitted Eo position
(no deadman opening possible)
Pos: null /Steuermodule/------------ Seitenumbruch ------------ @ 0\mod_1452083281983_0.docx @ 742 @ @
1
Pos: null /VTM_Torsteuerungen/Allgmeine Meldungen/Anzeige: 7-Segment +
Klartext/Informationsmeldungen während Parametrierung @ 0\mod_1528356234194_6.docx @ 20073 @
@ 1
Status messages during synchronization
7-Segment display
Real text display
Description
S.y.E.c.:
Start mit ↓
Synchronization of lower limit
position requested
(Jog Mode or wait for start
command)
S.y.E.o.
Start mit ↑
Synchronization of lower upper
position requested
(Jog Mode or wait for start
command)
S.y.E.1.
Zur Zwischenp.→↕
Synchronization of intermediate
stop position E1 (in deadman
mode)
S.y.op:
--
Automatic opening up to
mechanical stop, then automatic
synchronization of upper limit
position
S.y.cL
--
Automatic closing taking into
account safeties up to
mechanical stop, followed by
automatic synchronization of
lower limit position
S.y.c
Auto Syn. zu verr.
Automatic closing is locked due
to request Å
