TST
Assembly instructions
FUF2 / FU3F-A/-C/-F
FEIG ELECTRONIC GmbH
Page 101 of 114
TST_FUxF-A-C-F_Montageanleitung_EN_15
13 General messages
7-Segment +
Klartext/Statusm eldungen währe nd
Eichung/Synchro nisation @
0\mod_15283 54701138_6.docx
@ e
General messages
7-Segment display
Real text display
Description
FUF
FUF self test
Power Up and self test → Initial
display after power up
àUF@
Door closes.
Closing active
@AUF
Door opens.
Opening active
'Au'
Automatic
Automatic → indicates change
from "Manual" to "Automatic"
status
EICH
Calibration Start with Æ
CALI:→calibration setting the limit
positions in deadman travel mode
(for absolute encoder )→Start
procedure using STOP key
_Eu_
--
Lower limit position
Eu
Locked in close position
Lower limit position locked→
opening not possible (e.g. airlock)
-
Eo
-
--
Upper limit position
Eo
Locked in open position
Upper limit position locked→
closing not possible (e.g. Safety
edge)
-E1-
--
Middle limit position E1
(intermediate stop position)
E1
Locked in middle position
Middle limit position locked→
closing not possible
'Hc'
Semi-automatic
Semi-automatic→ indicates
change from "Manual" to "Semi-
automatic"
'Hd'
Dead man mode
Manual → Deadman mode
NA
Emergency stop
E-STOP → Movement not
possible, hardware safety chain
interrupted
HdSA:
Emergency travel
Emegency-travel→ Deadman
travel without regard for safeties,
etc.
ParA
Parametrization
Parametrization
FAIL
Fault
Fault → only deadman travel is
possible, automatic opening may
also be possible
STOP
STOP - Keypad
Stop / Reset-Modus → wait for
next incoming command
SYNC:
! Synchronised !
Synchronization (incremental
encoder / limit switch →
Pos.unknown)
