Feig Electronic TST FUF2 Series User Manual

TST
Assembly instructions
FUF2 / FU3F-A/-C/-F
FEIG ELECTRONIC GmbH
Page 47 of 114
TST_FUxF-A-C-F_Montageanleitung_EN_15
5.5.2 Connection of the TST LGB
TST LGB
Receiver
+24 V DC
GND
RS485 A
RS485 B
OUT2 – Photo eye
OUT1- Safety edge
TST LGB
Transmitter
86
-
Output 26
85
-
84
-
83
-
82
-
81
-
76
-
Output 25
75
-
74
-
73
-
+24V
72
-
Input 4
71
-
45 -
44 - GND
43 - Safety edge
42 - E-stop 1
41 - E-stop 1
36* - GND
35* - Channel B
34* - Channel A
33* - +12V
32* - E-stop 2
31* - E-stop 2
94
-
93
-
92
-
91
-
GND
GND GND
GND
Input 5
+24V
Input 6 Input 7
Input 11
+24V
Input 12
+12V
GND
IMPORTANT!
These wires connect
with each other
M12 /4 pole
Female
M12 /4 pole
Male
M12 /8 pole
Female
M12 /8 pole
Male
Pin 1 - brown
Pin 2 - white
Pin 3 - blue
Pin 4 - black
Pin 1 - white
Pin 2 - brown
Pin 3 - yellow
Pin 4 - green
Pin 5 - gray
Pin 6 - pink
Pin 7 - blue
Pin 8 - red
Figure 21: Connection of the TST LGB
