TST
Assembly instructions
FUF2 / FU3F-A/-C/-F
FEIG ELECTRONIC GmbH
Page 53 of 114
TST_FUxF-A-C-F_Montageanleitung_EN_15
5.7 Photo eye
G N D
+ 2 4 V
71
72
73
74
75
76
Receiver
Photo eye
+24 V
Input 5
GND
Figure 29: Connection of the photo eye
