Feig Electronic TST FUF2 Series User Manual

TST
Assembly instructions
FUF2 / FU3F-A/-C/-F
FEIG ELECTRONIC GmbH
Page 108 of 114
TST_FUxF-A-C-F_Montageanleitung_EN_15
USB Host (X403):
low-power USB memory stick with FAT32 file structure.
USB Profiles "Mass Storage Device" (8), Sub Class Code "SCSI
transparent command set" (6) Interface Protocol "Bulk-only
transfer" (0x50), Logical Unit Number (LUN 0), SCSI 'Request
Sense' <2.5 s, USB-Request Time <2.5 s, USB NAK <36684x, no
hubs / compounds possible!
Plug: USB Type A
Max power: 500 mA
Max. Cable length: 2 m
Type Record size per door cycle (log storage function): about
2 KByte
In case of permanent use of USB flash drives within the controller,
e.g. as log storage, must be observed temperature range.
Recommendation:
• • "Industrial grade" ""(typ.): 0 °C ... + 70 °C
• • "Extended industrial grade" (typ.): - 40 °C ... + 85 °C.
For not logging function:
For logging function:
Due to the large number of USB sticks available, the functionality
of each of these sticks cannot be guaranteed FEIG ELECTRONIC
GmbH recommends the USB sticks listed below:
AF8GUFNDNC-AADXX
USB-Stick, 8GB, USB 2, MLC, 0°C to 70°C
Manufacturer: Atp Electronics
AF4GUFNDNC(I)-AACXX
USB-Stick, 4GB, USB 2, SLC, -40°C to 85°C
Manufacturer: Atp Electronics
Alternatively, as a USB
Device (X401):
PC communication with FEIG service protocol
"Communication Device
à virtual serial port”
Plug USB Type B (mini-USB)
Max. Cable length: 2 m
Only one USB devices are connected to the interface!
Safety chain / Emergency
STOP
all inputs must be connect free of potential
Contact rating:  26 VDC /  120 mA
in case the safety chain is interrupted, the drive cannot be moved,
not even under Deadman conditions
Safety edge input 1 - "Si-
Lei" (cl. 43):
For electrical safety edges with 8,2 / 1,2kΩ terminating resistor
and for dynamic optical systems (Fraba)
Safety edge input 2 -
"IN10" (cl. 65):
For electrical safety edges with 8,2 / 1,2kΩ terminating resistor
and for dynamic optical systems (Fraba)
Shopfloor as a digital control input
Real-time clock:
24 hour clock with calendar function
4 chanel evaluation
Accuracy: less than 5 seconds per day over the entire
temperature range
Backup battery
holder prepared for lithium coin cell BR2032 (3 V)
Typical life: 5 Years
Battery not rechargeable! Dispose via exclusive lithium
battery disposal method (regional differences apply)!
