FUZ2 -A/-B/-C/-CX/-G/-L
Assembly instructions
TST
FEIG ELECTRONIC GmbH
Page 24 of 96
TST_FUZ2-A-B-C-CX-G-L_Montageanleitung_EN_22.docx
The following images show the installation of the heat sink with the controller:
Step 1: install additional heat sink
Use the following screws:
Use countersunk screw M4 DIN 965
Step 2: remove the spacer
Do not use spacers!
Step 3: install the controller
All four screws must be
completely recessed!
