TST
Assembly instructions
FUZ2 -A/-B/-C/-CX/-G/-L
FEIG ELECTRONIC GmbH
Page 49 of 96
TST_FUZ2-A-B-C-CX-G-
L_Montageanleitung_EN_22.docx
6.8 Photo eye
GND
+24V
71
72
73
74
75
76
Input 5
Receiver
photo eye
Figure 29: Phot eye connection
6.9 External triggering devices
+24V
OPEN
STOP
CLOSE
CLOSE
OPEN
STOP
52
51
54
53
Figure 30: Connection of external triggering devices
