FUZ2 -A/-B/-C/-CX/-G/-L
Assembly instructions
TST
FEIG ELECTRONIC GmbH
Page 26 of 96
TST_FUZ2-A-B-C-CX-G-L_Montageanleitung_EN_22.docx
5.4 Variants in steel or stainless steel housings
Steel and stainless steel housing variants are also available.
The housing has the following dimensions:
5.4.1 300 x 400 mm
300
255
400
440
T = 200
Figure 11: 300 x 400 housing
