Page #18 background image
Product overview
VEK MNH Operating Manual v1.3 en
18 | 56
Specifications
Inputs
1 x loop (1 x orange, single-channel variants)
2-pole terminal block (see Note 3)
2 x loop (1 x orange, dual-channel variants)
4-pole terminal block (see Note 3)
Outputs
2 x relays (1 x yellow, 1 x red, R24 variants)
3-pole terminal block (see Note 3)
Max. 48 V (AC/DC), 2 A, 60 W, 125 VA (SELV)
Min. 1 mA / 5 V (see note 2)
4 x open collector (2 x green, O24 variants)
3-pole terminal block (see Note 3)
27 V DC, 25 mA (SELV)
Configuration switch 1 (all variants)
8-pole DIP switch
Configuration switch 2 (dual-channel variants)
4-pole DIP switch
LED status indicator
1 x blue and 1 x red (per loop channel)
Reset button
Push button
PC interface
USB port, type mini AB
Tab. 6: Specifications
NOTE
1) Limitations on loop inductance
For loop inductances outside the recommended range, only one frequency level may be available.
For very small loop inductances, the maximum loop resistances are lower.
2) Current load of the relay contacts
The rigid gold plating on the relay contacts will be destroyed if the switching current exceeds 100
mA. Relays with contacts that are prestressed in this manner can only reliably switch currents over
100 mA!
3) Terminal block data
Grid dimension 5.0 mm, conductor cross-section 0.25 - 2.5 mm², AWG 24-12
