11.12 Setting direction logic (dual-channel variants)
A variety of evaluation logics can be set in the logic module, depending on the application.
NOTE
Switching direction detection on
It is only possible to set the direction logic when direction detection is activated!
DIP (Dir. Logic)
Detector Tool
Direction Logic
D1
Continuous signal 1
DB
Continuous signal, both loops
OFF
D2
Constant signal 2 (factory setting)
ON
F1
wrong-way driver 1
F2
Wrong-way driver 2
BS
both loops
FE
Feig
SF
Loop free
PB
Parking bay
OFF
No logic selected
Tab. 31: Setting direction logic
The different logics for direction detection are described below.
abbr.
Direction Logic
Signal output
Signal drop
Note
D1
Continuous
signal 1
Covering Loop 1
Leaving Loop 1
Output signal in opposite direction
only occurs again if both loops
were previously free.
DB
Continuous
signal both
Leaving Loop 2
D2
Continuous
signal 2
Covering Loop 2
F1
Wrong-way
driver 1
Covering Loop 2
Pulse output with
minimum signal
duration (default:
200 ms)
Correct behaviour in the case of
queues and manoeuvring.
Different behaviour in wrong-way
driver situation.
F2
Wrong-way
driver 2
BS
both loops
Correct behaviour in the case of
queues. Manoeuvring should not
occur.
FE
Feig
Leaving Loop 1
Correct behaviour in the case of
queues and manoeuvring.
SF
Loop free
Leaving Loop 2
Recording single vehicles and
manoeuvring. Queues should not
occur.
