VEK MNH Operating Manual v1.3 en
10.3 Reset button
The device is reset using the reset button on the front as follows:
runs a frequency readjustment and clears the LED fault
messages
resets the device to factory settings (DIP switch default
settings)
10.4 USB interface
Detailed configuration and diagnosis of the detector data are possible via the USB interface.
The free Detector Tool service program can be downloaded from the customer area at www.feig.de. In
addition, a computer and a USB cable of the Mini-AB type are required.
10.5
Detector Tool
service program
Registered users may download the Detector Tool free of charge from the download area under
www.feig.de.
You can find detailed information on the diagnostic functions and advanced configuration options in the
guide to the Detector Tool. The guide is also available in the download area.
Overwriting the DIP switch
Changes made with the Detector Tool overwrite the DIP switch settings. When this happens, the blue
LEDs flash continuously. In this case, the DIP switch positions may no longer be valid. Pressing the reset
button for 5 seconds resets to the factory settings and clears the LEDs (see section Reset button).
Configuring the detector
The Detector Tool offers additional settings and parameters for configuring the device on top of those offered
by the DIP switches. These include, for example, loop sensitivity, hysteresis (drop in threshold value), hold
time, behaviour in the event of loop errors, output signal functions, direction detection and switch-on or
switch-off delay on the relays.
Diagnostic data indicator
You can evaluate the current diagnostic data with the Detector Tool. These include, for example, loop
frequency, detuning of the induction loops and their chronological sequences, the current status of the loops,
the last maximum retuning, the last occupancy duration, the period between two occupancies, the elapsed
hold time, the status of the relays, and the travel direction detected.
