Description of functions
VEK MNH Operating Manual v1.3 en
32 | 56
DIP2
Designation
Function
1
Dir. Mode
Direction detection
2
Dir. Logic
Direction Logic
3
Inv. Out 1
Output signal 1 inversion
4
Inv. Out 2
Output signal 2 inversion
Tab. 14: DIP switch 2 assignment (standard)
The following parameters can be adjusted with the DIP switch:
DIP switch
Position
Value
Sense 1a / 2a
ON
0.01% (high)
Sense 1b / 2b
ON
Sense 1a / 2a
OFF
0,04%
Sense 1b / 2b
ON
Sense 1a / 2a
ON
0,16%
Sense 1b / 2b
OFF
Sense 1a / 2a
OFF
0.64% (low)
Sense 1b / 2b
OFF
Frequency
OFF
low
ON
high
Hold time
OFF
5 minutes
ON
Infinite
Output 2
OFF
Continuous signal
ON
Pulse signal
Edge 2
OFF
on entering
ON
on leaving
Inv. Out 1
OFF
inverted
ON
not inverted
Inv. Out 2
OFF
not inverted
ON
inverted
Dir. Mode
OFF
Presence
ON
Direction
Dir. Logic
OFF
Continuous signal 2
ON
Wrong-way driver 1
Tab. 15: Settings via DIP switch (dual-channel)
