Assembly and electrical installation
VEK MNH Operating Manual v1.3 en
8.5 Connecting the induction loops
The requirements for the induction loops differ according to the area of application. Allow the supplier to
advise you on installation of the induction loops.
The induction loops are already installed and ready for use.
• Insulated slotted screwdriver (width: 2 – 3 mm)
• Induction loops for the respective area of application
Connecting the induction loops
1. Follow the warning and safety instructions and take the appropriate precautions.
2. If necessary, pull the orange terminal block out of the socket.
3. Loosen the screws on the blue terminal block.
4. Insert up to 5 mm of stripped cable into the slot on the side of the terminal block and fasten.
5. Tighten the screw.
6. If necessary, insert the terminal block back into the orange 4-pole socket.
The induction loops are firmly attached with no exposed wires.
