10.2 DIP switch settings
Further information
• You can find detailed information on settings options in the section Description of settings.
• The Detector Tool service program offers further settings options. For information on these, read the
section on the Detector Tool.
• If the settings are changed with the Detector Tool, the DIP switch settings are no longer valid. This
will be indicated by the blue LEDs flashing. Also read the section on the Reset button.
Switch-on threshold for the signal output when a loop is covered
Frequency of the loop oscillating circuit in two levels
Hold time until readjustment
Maximum duration of the output signal up to the automatic frequency
readjustment of the loop channel
Switching between continuous and pulse signal on output 2
Time of output signal for activated pulse signal on output 2
Switching between open circuit (not inverted) and closed circuit principle
(inverted) for the output signals
Switching between presence and travel direction detection for both
outputs (dual-channel variants)
Evaluation logic of the travel direction when loops are covered,
depending on the application (see full operating manual!)
Tab. 10: Description of the settings
The single-channel variants have an 8-pole DIP switch for configuring the detector.
Hold time until readjustment
Output signal 1 inversion
Output signal 2 inversion
Tab. 11: DIP switch assignment (default)
