Description of functions
VEK MNH Operating Manual v1.3 en
31 | 56
The following parameters can be adjusted with the DIP switch:
DIP switch
Position
Value
Sense a
ON
0.01% (high)
Sense b
ON
Sense a
OFF
0,04%
Sense b
ON
Sense a
ON
0,16%
Sense b
OFF
Sense a
OFF
0.64% (low)
Sense b
OFF
Frequency
OFF
low
ON
high
Hold time
OFF
5 minutes
ON
Infinite
Output 2
OFF
Continuous signal
ON
Pulse signal
Edge 2
OFF
on entering
ON
on leaving
Inv. Out 1
OFF
inverted
ON
not inverted
Inv. Out 2
OFF
not inverted
ON
inverted
Tab. 12: Settings via DIP switch (single-channel)
The dual-channel variants have an 8-pole and 4-pole DIP switch for configuring the detector.
DIP1
Designation
Function
1
Sense 1a
Loop 1 sensitivity
2
Sense 1b
Loop 1 sensitivity
3
Sense 2a
Loop 2 sensitivity
4
Sense 2b
Loop 2 sensitivity
5
Frequency
Frequency level
6
Hold time
Hold time until readjustment
7
Output 2
Output signal 2 mode
8
Edge 2
Output signal 2 time
Tab. 13: DIP switch 1 assignment (standard)
