2. Parameters of the SPC11 for the DGP(I)(L)-...
2-6
Festo P.BE-SPC11 -DGP-EN en 0012NH
The average positioning times specified apply to the maxi-
mum permitted stroke (without cushioning path). Optimiz-
ation of the positioning behaviour may be necessary in indi-
vidual cases (see System manual).
DGP(I)(L)-25-225 to ...-25-300
DGP(I)(L)- 25-225 DGP(I)(L)-25-300
MPYE-5-1/8- LF- 010B MPYE- 5-1/8- LF-010B
Mass load [kg]
Amplification stage
Cushioning stage
System parameter
Time upwards [s]
Time downwards [s]
Amplification stage
Cushioning stage
System parameter
Time upwards [s]
Time downwards [s]
2 8 15 01
0.49 0.44
12 16 02
0.51 0.45
4 11 18 01
0.50 0.44
14 19 02
0.57 0.48
1 Proportional directional control valve
required
2 Cylinder type
3 Average positioning time in seconds
for maximum permitted stroke (with-
out cushioning path), deviations
usually lie within ± 70 ms
4 Maximum permitted mass load for the
adjacent parameter setting
Fig. 2/1: Explanation of table structure
