Pressure values
Channel 25, adressed target 11
Index Meaning Value digit
163 Pressure at valve 7, working air port (4) (absolute) 0.001 bar
164 Pressure at valve 7, working air port (4) (relative) 0.001 bar
Tab. 66: Pressure values
Temperatures
Channel 25, addressed target 12
Index Meaning Value digit
1 Temperature at supply pressure sensor at port (1) 0.1 °C
3 Temperature at exhaust pressure sensor at port (1) 0.1 °C
5 Temperature at atmospheric pressure sensor 0.1 °C
21 Temperature at valve 0, working air port (2) 0.1 °C
23 Temperature at valve 0, working air port (4) 0.1 °C
41 Temperature at valve 1, working air port (2) 0.1 °C
43 Temperature at valve 1, working air port (4) 0.1 °C
61 Temperature at valve 2, working air port (2) 0.1 °C
63 Temperature at valve 2, working air port (4) 0.1 °C
81 Temperature at valve 3, working air port (2) 0.1 °C
83 Temperature at valve 3, working air port (4) 0.1 °C
101 Temperature at valve 4, working air port (2) 0.1 °C
103 Temperature at valve 4, working air port (4) 0.1 °C
121 Temperature at valve 5, working air port (2) 0.1 °C
123 Temperature at valve 5, working air port (4) 0.1 °C
141 Temperature at valve 6, working air port (2) 0.1 °C
143 Temperature at valve 6, working air port (4) 0.1 °C
161 Temperature at valve 7, working air port (2) 0.1 °C
163 Temperature at valve 7, working air port (4) 0.1 °C
Tab. 67: Temperatures
