Supported peripherals
103
Digital input module CTMM-…-D-…
Interface M8, 3-pin
Behaviour Voltage input 24 V DC
Input characteristic In accordance with IEC 61131-2, type 3
Switching logic PNP, NO (normally open)
Switching level
Signal 0 [V DC] £ 5
Signal 1 [V DC] ³ 11
Tab. 135: Digital input module
Analogue input module CTMM-…-A-…
Interface M8, 4-pin
Behaviour Current input 4 … 20 mA
Compatible sensors SDAP-MHS-M...-1L-A-E-0.3-M8
Tab. 136: Analogue input module
6 Supported peripherals
6.1 Supported CPX bus nodes
The CPX terminal can establish the connection to a higher-order controller via one of the following bus
nodes:
Type code Identifier Protocol
CPX-FB11 Bus node DeviceNet
CPX-FB13 Bus node PROFIBUS
CPX-FB14 Bus node CANopen
CPX-FB23-24 Bus node CC-LINK
CPX-FB33 Bus node PROFINET
CPX-FB36 Bus node EtherNet/IP, Modbus TCP
CPX-FB37 Bus node EtherCAT
CPX-FB38 Bus node EtherCAT
CPX-FB39 Bus node Sercos III
CPX-FB40 Bus node Ethernet POWERLINK
1)
CPX-FB45 Bus node PROFINET
T32 CoDeSys embedded controller RS232 (S1)
