Function
ID Value range Composition of the value (calculation of
digits)
70 20 … 27
(valve terminal with 2 valve slots and a slot
for input modules)
[slot input module] ×10 + [number sensor
input] × 1
40 … 47 and 50 … 57
(valve terminal with 4 valve slots and 2 slots
for input modules)
80 … 87 and 90 … 97
(valve terminal with 8 valve slots and 2 slots
for input modules)
Tab. 80: Sensor input for end position sensing, retracted
3.6.3.2 Sensor input for end position sensing, advanced((4) pressurised, (2) exhausted)
This parameter must only be used if proximity sensors are used and should be evaluated in the return
value (optional). The value for the parameter is calculated from the position of the input module (valve
slot), multiplied by a factor of 10 and then added to the number of the input on this input module
(0 … 7).
ID Value range Composition of the value
(calculation of digits)
71 20 … 27
(valve terminal with 2 valve slots and a slot
for input modules)
[slot input module] ×10 + [number sensor
input] × 1
40 … 47 and 50 … 57
(valve terminal with 4 valve slots and 2 slots
for input modules)
80 … 87 and 90 … 97
(valve terminal with 8 valve slots and 2 slots
for input modules)
Tab. 81: Sensor input for end position sensing, advanced
3.6.4 Application parameters used
Operating mode
The parameter enables the definition of the valve behaviour in relation to internal air consumption and
compatibility for a fast change between Motion Apps.
Possible operating modes:
–
Controlled:
