Fiat 500D - Sectional View of Right Side Rear Wheel and Axle Shaft

TOOL A.66062
SUPPORT C. 696/3
GAUGE C.696
FIG 7:12 Checking left rear wheel toe-in
ARM C. 696/3
GAUGE C.696
FIG 7:11 Checking left rear wheel toe-in
F500
FIG 7:13 Sectional view of right side rear wheel and axle shaft
NOTE—This assembly differs from the early design in the following items: control arm, handbrake shoe actuating lever,
flexible joint, axle shaft-to-flexible joint sleeve, sleeve snap ring, axle shaft and joint casing.
85
