IN CASE OF EMERGENCY
146
tool bag fig. 175 located on the left of
the boot by releasing the elastic straps
and take to the wheel to be replaced;
175 F0T0206
take wheel spanner (B) fig. 176 and
the extension with pentagonal fitting
(C); inside the load area, fit extension
(C) on bolt (A); use spanner (B) to lower
the wheel by unwinding the wire;
176 F0T0922
use the wheel spanner (B) to remove
the wheel from the vehicle fig. 177;
unscrew knob (D) fig. 178 and
release the rim from bracket (E),
removing it from the hole of the rim;
177 F0T0168
for vehicles with alloy rims, remove
the hub cap;
loosen the fixing bolts of the wheel to
be replaced by about one turn, using
the spanner provided;
for wheels with steel rims, remove
the wheel cap;
178 F0T0923
turn the jack to open it partially and
then position it under the vehicle at the
references (A) fig. 179 near the wheel
to be replaced;
