25
20 F0T0375
Opening/closing the first swing
door from the outside
To open the door, turn the metallic
insert of the key in the lock or press
button on the remote control
and then pull handle (A) fig. 21 in the
direction of the arrow.
21 F0T0140
To close the door, turn the key in the
lock or press button on the remote
control.
12)
Emergency opening of the first
swing door from the inside
From inside, use device (A) fig. 22.
22 F0T0060
Opening the second swing door
After having opened the first door, pull
handle (A) fig. 23 in the direction shown
by the arrow.
WARNING Pull handle (A) fig. 23 in the
direction of the arrow only.
23 F0T0142
WARNING
6)
Before opening a door, ensure that you
can do it in conditions of safety.
7)
The right sliding side door cannot be
opened with the fuel flap open during
refuelling.
8)
Do not leave the sliding side door open
when the vehicle is parked on a gradient.
A knock could release the latch leaving the
door free to move forward.
9)
Before leaving the vehicle parked with
sliding doors open, always check that the
latch is engaged.
10)
Always use this device when carrying
children.
11)
This spring loaded system has
activation forces that were designed for
optimum comfort. Accidental knocks
or a strong gust of wind may release
the springs and let the doors close
spontaneously.
12)
When closing, shut the right hand door
(2) fig. 19 fully before you close the left
hand door (1) fig. 19. Never shut the two
doors at the same time.
IMPORTANT
2)
Make sure that the right sliding side
door is all closed before refuelling to
prevent damage to the door and to the
sliding locking system with fuel filler
cap open, activated during refuelling
operations.
