KNOWING YOUR VEHICLE
24
15 F0T0209
Opening/closing from the inside
(Fiorino Combi versions)
Opening: pull lever (A) fig. 16 and slide
the door towards the rear of the vehicle
until it can go no further.
16 F0T0137
To close: Use the handle (A) fig. 17 to
close the sliding side door, sliding it
towards the front of the vehicle.
17 F0T0197
Opening/closing from the inside
(Fiorino Cargo versions)
WARNING The rear sliding side door
has no internal opening handle. If
necessary, use device (A) fig. 22 of the
rear double swing door.
CHILD SAFETY DEVICE
10)
This system prevents opening the
sliding side doors from the inside.
1
2
18 F0T0138
The device can be engaged only with
the sliding side door open fig. 18:
(1) position - device engaged (door
locked);
position (2) - device not engaged
(door may be opened from the inside).
The device remains engaged even if the
doors are electrically unlocked.
DOUBLE REAR WING
DOORS
(for versions/markets, where provided)
The double rear swing doors fig. 19 are
fitted with a spring-loaded system that
stops them when they have opened to
an angle of approximately 90 degrees.
19 F0T0139
To open them wider to an angle of 180
degrees, push the locking device (A)
fig. 20 (one on each side) as shown in
the diagram and simultaneously open
the doors.
11)
