KNOWING YOUR VEHICLE
46
doors with the remote control or using
the key without remote control.
The tailgate unlocks also by pressing
the button on the remote control.
To close the tailgate use handle (B)
fig. 70.
30)
EMERGENCY OPENING
FROM THE INSIDE
(Qubo version)
71 F0T0285
In the event of an emergency, you can
open the tailgate from inside as follows:
Open the sliding side door and fully
fold the rear seats;
from inside the boot, press lever (A)
fig. 71 and open the tailgate.
31) 32)
EMERGENCY OPENING
FROM THE INSIDE
(Fiorino version)
In the event of an emergency, you can
open the tailgate from inside as follows:
open the sliding side door and lower
the backrest of the rear seat to gain
access to the boot (Combi versions);
or
72 F0T0060
open the sliding side door (Cargo
versions);
use device (A) fig. 72 located on the
inside of the right-hand swing door;
open the left-hand swing door by
pulling the handle (see "Doors" in this
section).
31) 32)
DOUBLE REAR WING
DOORS
(for versions/markets, where provided)
The double rear swing doors fig. 73 are
fitted with a spring-loaded system that
stops them when they have opened to
an angle of approximately 90 degrees.
73 F0T0139
To open them wider to an angle of 180
degrees, push the locking device (A)
fig. 74 (one on each side) as shown in
the diagram and simultaneously open
the doors.
33) 34)
74 F0T0375
