Fibocom L860-GL-16 User Manual

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM L860-GL Series Hardware Guide Page 11 of 60
2 Overview
2.1 Introduction
L860 is a highly integrated 4G WWAN module which uses M.2 form factor interface. It supports LTE
FDD/LTE TDD/WCDMA systems and can be applied to most cellular networks of mobile carrier in the
world.
2.2 Specification
Specification
Operating Band
LTE FDD: Band 2, 4, 5, 7, 12, 13, 14, 17, 25, 26, 29, 30, 66, 71
LTE TDD: Band 38, 41(HPUE), 48
LAA Band 46 Receiver only
4x4MIMO support: Band 2, 4, 7, 25, 30, 38, 41, 48, 66
WCDMA/HSPA+: Band 2, 4, 5
GNSS
Support GPS, BDS, GLONASS, Galileo
LTE
3GPP Release 13
UMTS
3GPP Release 12
Data Transmission
LTE FDD
LTE FDD: 1Gbps DL (Cat 16)/50Mbps UL (Cat 13)
LTE TDD
LTE TDD: 756Mbps DL (Cat 16)/90Mbps UL (Cat 13)
UMTS/HSPA+
UMTS:384 kbps DL/384 kbps UL
DC-HSPA+:42 Mbps DL (Cat 24)/5.76 Mbps UL (Cat6)
Carrier Aggregation
5CA Downlink /2*ULCA (Intra band) UL 64QAM Support
Power Supply
DC 3.135V-4.4V, Typical 3.3V
Temperature
Normal operating temperature: -10°C-+55°C
Extended operating temperature: -20°C-+65°C
Storage temperature: -40°C-+85°C
Physical
Characteristics
Interface: M.2 Key-B
Dimension
：
30×42×2.3mm
Weight: About 6.2 g
Interface
Antenna Connector
WWAN Antenna×4
