FIBOCOM L860-GL Series Hardware Guide Page 55 of 60
6 Structure Specification
6.1 Product Appearance
The product appearance for L860 module is shown in Figure6-1:
Figure 6-1 Module appearance
Note
The label of each module is subject to the good shipped.
6.2 Dimension of Structure
The structural dimension of the L860 module is shown in Figure 6-2:
Fibocom
Confidential
