FIBOCOM L860-GL Series Hardware Guide Page 49 of 60
Operating Band
Description
Mode
Tx (MHz)
Rx (MHz)
Band 66
1700MHz
LTE FDD
1710-1780
2110-2200
Band 71
680MHz
LTE FDD
663-698
617-652
Band 38
2600MHz
LTE TDD
2570-2620
Band 41
2500MHZ
LTE TDD
2496-2690
Band 48
3600MHZ
LTE TDD
3550-3700
Band 46
5200MHZ
LTE TDD
N/A
5150-5925
GPS L1
-
-
-
1575.42±1 .023
GLONASS L1
-
-
-
1602.5625±4
BDS
-
-
-
1561.098±2.046
Galileo
-
-
-
1575.42±1.023
4.3 Transmitting Power
The transmitting power for each band of L860 module is shown in the following table:
Mode
Band
3GPP Requirement (dBm)
Tx Power (dBm)
Note
WCDMA
Band 2
24+1.7/-3.7
23.5±1
-
Band 4
24+1.7/-3.7
23.5±1
-
Band 5
24+1.7/-3.7
23.5±1
-
LTE FDD
Band 2
23±2.7
23±1
10MHz Bandwidth, 1 RB
Band 4
23±2.7
23±1
10MHz Bandwidth, 1 RB
Band 5
23±2.7
23+2/-1
10MHz Bandwidth, 1 RB
Band 7
23±2.7
23±1
10MHz Bandwidth, 1 RB
Band 12
23±2.7
23+2/-1
10MHz Bandwidth, 1 RB
Band 13
23±2.7
23+2/-1
10MHz Bandwidth, 1 RB
Band 14
23±2.7
23+2/-1
10MHz Bandwidth, 1 RB
Band 17
23±2.7
23+2/-1
10MHz Bandwidth, 1 RB
Band 25
23±2.7
23±1
10MHz Bandwidth, 1 RB
Band 26
23±2.7
23+2/-1
10MHz Bandwidth, 1 RB
Band 30
23±2.7
22±1
10MHz Bandwidth, 1 RB
Fibocom
Confidential
