FIBOCOM L860-GL Series Hardware Guide Page 51 of 60
Mode
Band
3GPP Requirement
(dBm)
Rx Sensitivity (dBm)
Typical
Note
Band 66
-95.8
-101.5
10MHz Bandwidth
Band 71
-93.5
-101.4
10MHz Bandwidth
LTE TDD
Band 38
-96.3
-100.2
10MHz Bandwidth
Band 41
-94.3
-99.4
10MHz Bandwidth
Band 46
-88.5
-95.5
20MHz Bandwidth
Band 48
-95
-101.3
10MHz Bandwidth
Note:
The above values are measured in dual antennas condition (Main+Diversity). For single main
antenna (without Diversity), the sensitivity will drop about 3dBm for each band of LTE.
Four Antennas Receiver Sensitivity
Some middle/high bands support four antennas. The receiver sensitivity for some middle/high bands of
L860 module is shown in below table:
Mode
Band
Middle/High
Band
3GPP Requirement
(dBm)
Rx Sensitivity
Typical (dBm)
Note
LTE FDD
Band 2
Middle Band
-97
-103.5
10MHz Bandwidth
Band 4
Middle Band
-99
-103.5
10MHz Bandwidth
Band 7
High Band
-97
-103
10MHz Bandwidth
Band 25
Middle Band
-95.5
-103
10MHz Bandwidth
Band 30
High Band
-98
-103
10MHz Bandwidth
Band 66
Middle Band
-98.5
-103.5
10MHz Bandwidth
LTE TDD
Band 41
High Band
-97
-103
10MHz Bandwidth
Band 48
High Band
-97.2
-103.8
10MHz Bandwidth
Note:
The above values are measured in four antennas condition (Main+Diversity+M1+M2). If only use
dual antennas (Main+Diversity), the sensitivity will drop about 3dBm for each band of LTE.
