FIBOCOM L860-GL Series Hardware Guide Page 26 of 60
Parameter
Mode
Condition
Typical
Current (mA)
LTE TDD Data call Band 41 @+23dBm
620
LTE TDD Data call Band 48 @+21dBm
400
Note：
The above data is the average value obtained by testing the sample for high/medium/low
channels.
In 5CA mode, the L860 power consumption is shown in the following table:
5CA Combination
Condition
(Max Data Transfer)
Typical
Current (mA)
2+46+46+46+46, 46+46+46+46+66,
2+5+5+30+66, 2+5+5+66+66,
2+2+46+46+46, 2+5+46+46+46,
2+13+46+46+46, 2+46+46+46+46,
2+46+46+46+66, 4+46+46+46+46,
5+46+46+46+66, 13+46+46+46+66,
46+46+46+66+66, 2+46+46+46+46,
5+46+46+46+46, 13+46+46+46+46,
41+41+41+41+41
Band 2 @+22dBm
1650
Band 5 @+22dBm
1300
Band 7 @+22dBm
1600
Band 13 @+22dBm
1350
Band 30 @+22dBm
1350
Band 41 @+22dBm
1000
Band 66 @+22dBm
1500
Note：
The data above is an average value tested on some samples at 25°C temperature.
3.3 Control Signal
The L860 module provides two control signals for power on/off and reset operations. The pin is defined in
the following table:
Pin
Pin Name
I/O
Reset Value
Function
Type
6
FULL_CARD_POWER
_OFF#
I
PU
Module power on/off input,
internal pull up
Power on: High/Floating
Power off: Low
3.3/1.8V
67
RESET#
I
PU
WWAN reset input, internal pull up
(10KΩ), active low
1.8V
