FIBOCOM L860-GL Series Hardware Guide Page 34 of 60
Timing Application
The recommended timing application in Win10 OS is as below table:
Refer to section 3.3.4.1 Figure 3-10 D0 L1.2 timing
Refer to section 3.3.4.2 Figure 3-11/3-12 D3
cold
L2 timing
Refer to section 3.3.1.2 Figure 3-5 Timing control for start-up
Refer to section 3.3.2 Figure 3-6 Shutdown timing control
Refer to section 3.3.1.2 Figure 3-5 Timing control for start-up
Refer to section 3.3.3 Figure 3-9 Reset control timing2
nd
Modem FW upgrade / Modem
recovery
Refer to section 3.3.3 Figure 3-8 Reset control timing1
st
Intel X86 platforms must follow the table above. AMD X86 platforms should follow the table above and
meet the special request of platform itself.
The recommended timing application in Chrome/Android/Linux OS is as below table:
Refer to section 3.3.1.2 Figure 3-5 Timing control for start-up
Refer to section 3.3.2 Figure 3-6 Shutdown timing control
Refer to section 3.3.4.1 Figure 3-10 D0 L1.2 timing /
section 3.3.4.2 Figure 3-11/12 D3
cold
L2 timing
Refer to section 3.3.3 Figure 3-9 Reset control timing2
nd
Modem FW upgrade / Modem
recovery
Refer to section 3.3.3 Figure 3-8 Reset control timing1
st
3.4 PCIe Interface
L860 module supports PCIe Gen2, one lane for data transmission channel. It is also compatible with PCIe
Gen1. After L860 module is inserted into PC, PCIe interface can work with the driver, and then map a
MBIM port and a GNSS port in Win10 & Linux system. MBIM interface is used for initiating data service in
Win10 & Linux system and GNSS interface is used for receiving GNSS data.
