FIBOCOM L860-GL
Series Hardware G
uide
Page
60
of
60
T
ra
y
Size
The pallet siz
e is 315×1
70×6.
5mm, and is s
hown in Fig
ure 6-6:
Figure 6-6
T
ray size (un
it: mm)
ITEM
DIM (Unit
: mm)
L
315.0±2.0
W
170.0±2.0
H
6.5±0.3
T
0.8±0.1
A
43.0±0.3
B
31.0±0.3
C
79.0±0.2
D
60.0±0.2
E
180.0±0.2
F
60.0±0.2
G
40.0±0.2
Fibocom
Confidential
59
