FIBOCOM L860-GL Series Hardware Guide Page 48 of 60
Figure 4-8 Pulling direction
4.2 Operating Band
The operating bands of L860 module are shown in the following table:
Operating Band
Description
Mode
Tx (MHz)
Rx (MHz)
Band 2
1900MHz
LTE FDD/WCDMA
1850-1910
1930-1990
Band 4
1700MHz
LTE FDD/WCDMA
1710-1755
2110-2155
Band 5
850MHz
LTE FDD/WCDMA
824-849
869-894
Band 7
2600Mhz
LTE FDD
2500-2570
2620-2690
Band 12
700MHz
LTE FDD
699-716
729-746
Band 13
700MHz
LTE FDD
777-787
746-756
Band 14
700MHz
LTE FDD
788-798
758-768
Band 17
700MHz
LTE FDD
704-716
734-746
Band 25
1900MHz
LTE FDD
1850-1915
1930-1995
Band 26
850MHz
LTE FDD
814-849
859-894
Band 29
700MHz
LTE FDD
N/A
716-728
Band 30
2300MHz
LTE FDD
2305-2315
2350-2360
Fibocom
Confidential
