FIBOCOM L860-GL Series Hardware Guide Page 22 of 60
Pin
Pin Name
I/O
Reset Value
Pin Description
Type
75
CONFIG_2
O
NC
NC, L860 M.2 module is configured as
the WWAN – PCIe, USB3.0 interface
type
-
Reset Value: The initial status after module reset, not the status when working.
 H: High Voltage Level
 L: Low Voltage Level
 PD: Pull-Down
 PU: Pull-Up
 T: Tristate
 OD: Open Drain
 PI: Power Input
 PO: Power Output
Note:
The unused pins can be left floating.
3.2 Power
The power interface of L860 module is shown in the following table:
Pin
Pin Name
I/O
Pin Description
DC Parameter (V)
Minimum
Value
Typical
Value
Maximum
Value
2, 4, 70, 72, 74
+3.3V
PI
Power supply input
3.135
3.3
4.4
36
UIM_PWR
PO
USIM power supply
-
1.8V/3V
-
48
UIM2_PWR
PO
USIM power supply
-
1.8V/3V
-
L860 module uses PCIe interface. According to the PCIe specification, the PCIe Vmain should be used as
the +3.3V power source, not the Vaux. The Vaux is the PCIe backup power source and it is not sufficient
as the power supply. In addition, the DC/DC power supply other than PCIe ports should not be used as
the external power cannot control the module status through the PCIe protocol.
