L860 Module Main Antenna Requirement
Frequency range
The most proper antenna to adapt the frequencies should be used.
Bandwidth (WCDMA)
WCDMA band 2 (1900): 140 MHz
WCDMA band 4 (1700): 445 MHz
WCDMA band 5 (850): 70 MHz
Bandwidth (LTE)
LTE band 2 (1900): 140MHz
LTE band 4 (1700): 445MHz
LTE band 5 (850): 70 MHz
LTE band 7 (2600): 190 MHz
LTE Band 12 (700): 47 MHz
LTE Band 13 (700): 41 MHz
LTE Band 14 (700): 40 MHz
LTE Band 17 (700): 42 MHz
LTE band 25 (1900):145 MHz
LTE band 26 (850): 80 MHz
LTE band 29 (700): 12 MHz
LTE band 30 (2300): 55 MHz
LTE band 66 (1700): 490MHz
LTE band 38 (2600): 50 MHz
LTE band 41 (2500): 194 MHz
LTE band 48 (3600):150MHz
LTE band 46 (5GHz): 775 MHz
Bandwidth (GNSS)
GPS: 2 MHz
GLONASS: 8 MHz
BDS: 4 MHz
Galileo: 2 MHz
Impedance
50Ω
Input power
> 28 dBm average power WCDMA & LTE
Recommended standing-wave
ratio (SWR)
≤ 2:1
Note:
ANT on B30 suggestion: Peak gain < 1dBi, for FCC EIRP requirement, Efficient > 50% for
carrier TRP requirement. If integrator doesn't follow the instruction, may cause FCC EIRP or
carrier TRP certification fail.
