Fike ECS Series - Electrical Specifications

14 ECS Series Manual — P/N LS10262-001FK-E:A 3/3/2021
Installation Electrical Specifications
Figure 3.2 Wire Routing FCP-2100ECS
3.3 Electrical Specifications
* Fully loaded system
Relay
outputs
AC Power
Input
lines
SLC
devices
devices
To Phone
SBUS
Module Voltage
Standby
Current
*Alarm
Current
FIK-50W 25V 120V 60 Hz 350 mA 1100 mA
FIK-50W 25V 240V 50/60 Hz 200 mA 600 mA
FIK-50W 70V 120V 60 Hz 350 mA 1200 mA
FIK-50W 70V 240V 50/60 Hz 200 mA 600 mA
Table 3.1 FIK-50W AC Current Draw
Module Voltage
Standby
Current
*Alarm
Current
FIK-125W 25V 120V 60 Hz 300 mA 2200 mA
FIK-125W 25V 240V 50 Hz 250 mA 1250 mA
Table 3.2 FIK-125W AC Current Draw
Module Voltage
Standby
Current
*Alarm
Current
FIK-DUAL50W 25V 120V 60 Hz 210 mA 2510 mA
FIK-DUAL50W 25V 240V 50/60 Hz 260 mA 1525 mA
FIK-DUAL50W 70V 120V 60 Hz 210 mA 2650 mA
FIK-DUAL50W 70V 240V 50/60 Hz 260 mA 1600 mA
Table 3.3 FIK-DUAL50W AC Current Draw
