16 ECS Series Manual — P/N LS10262-001FK-E:A 3/3/2021
Installation Installing ECS Series Cabinets
3.4.3 Surface Mounting the FIK-LOC Cabinet
The cabinets can be mounted on the wall surface by using the mounting holes in the back of the cabinet (see Figure 3.4).
The FIK-LOC is a combination FIK-RVM Remote Voice Module and its associated FIK-RA2000 annunciator. The FIK-LOC is compatible
with the FCP-300. For more information, refer to Installation manuals for the FACP. Cabinet dimensions are 20.362" W x 27" H x 5.054" D.
Figure 3.4 FIK-LOC Cabinet Mounting Holes
27"
20.362"
Bottom Mounting
Holes
Key Shaped Holes
