Section 1: Overview
The Emergency Communication System Packages are a combination of the addressable fire alarm control panel and voice integration control
all in one package. The general idea of the Emergency Communication System is to activate a message giving building occupants instruc-
tions about an emergency event. This manual contains information on how to install and operate the following Emergency Communication
System Packages:
1.1 Optional Accessories
This manual also contains information on how to install the following compatible accessory with the ECS series equipment:
1.2 ECS Features
• Single enclosure for both Fire and Emergency Control System components.
• Onboard supervised microphone
• Supports 25 Vrms or 70.7 Vrms speaker circuits using FIK-50W, FIK-INT50W, or FIK-DUAL50W. Supports 25 Vrms using FIK-
125W.
• Network Voice Control Module (FIK-NVCM)
• FCP-2100ECS or FCP-300ECS have support for one FIK-NVCM.
• Built in Digital Message Repeater
• 15 ECS Messages
• FCP-300ECS and FCP-2100ECS systems have support for dual channel and backup audio using the FIK-DUAL50W amplifier and
FIK-50WBU back-up amplifier.
• SBUS Addressable Amplifier
• FCP-300ECS systems support a combination of up to eight FIK-50Ws, FIK-125Ws or FIK-DUAL50Ws for a maximum of 1000
watts per system.
• FCP-2100ECS has support for up to 16 FIK-50Ws, FIK-125Ws, FIK-INT50Ws, or FIK-DUAL50Ws for a maximum of 2000 watts
per system and up to 128 mappable speaker circuits.
• Local Operator Console (LOC)
• FCP-300ECSFIK-LOCs
• FCP-2100ECS Systems can support up to 15 FIK-2100LOCs
• Mappable Speaker Circuits
• FCP-300ECS systems can support up to 64 mappable speaker circuits using a combination of FIK-50Ws, FIK-125Ws, FIK-
DUAL50Ws and FIK-CE4s.
• FCP-2100ECS systems can support up to 128 mappable speaker circuits using a combination of the FIK-50W, FIK-125W, FIK-
DUAL50W, FIK-INT50W, and FIK-CE4.
• Backup Amplifier
• FIK-DUAL50Ws are capable of providing 50 watts of backed up audio power with the addition of the FIK-50WBU.
• ECS messages can be selected as priority over fire.
Model Number Consists of These Part Numbers
FCP-300ECS FCP-300
FIK-NVCM (Network Voice Control Module)
FCP-2100ECS FCP-2100
FIK-NVCM (Network Voice Control Module)
FIK-LOC FIK-RVM (Remote Voice Module)
FIK-RA2000 (Remote Annunciator)
FIK-LOC2100 FIK-RVM (Remote Voice Module)
FIK-RA2000 (Remote Annunciator)
Model Number Description Compatible With
FIK-SW24 Adds 24 additional switches to the FIK-NVCM or FIK-RVM to
manually select various voice output groups for emergency
announcements from the onboard microphone.
FCP-300ECS and FCP-2100ECS
FIK-50W 50 watt amplifier with 4 separate audio circuits. FCP-300ECS and FCP-2100ECS
FIK-125W 125 watt amplifier with 4 separate audio circuits. FCP-300ECS and FCP-2100ECS
FIK-CE4 Provides four additional audio circuits for each FIK-50W or FIK-125W. FIK-50W or FIK-125W
FIK-NVCM Network Voice Control Module FCP-300ECS and FCP-2100ECS
FIK-RVM Remote Voice Module FCP-300ECS and FCP-2100ECS
FIK-LOC Local Operating Console FCP-300ECS,
FIK-LOC2100 Local Operating Console FCP-2100ECS
FIK-DUAL50W Dual 50W Amplifier FCP-300ECS and FCP-2100ECS
FIK-50WBU External Backup Amplifier FCP-300ECS,
FIK-INT50W 50 watt internal amplifier FCP-300ECS and FCP-2100ECS
