44 ECS Series Manual — P/N LS10262-001FK-E:A 3/3/2021
Device Installation Installing the FIK-125W
Figure 4.37 Connecting FIK-125W to the SBUS using FIK-NVCM
Figure 4.38 Connecting Multiple FIK-125Ws to the SBUS using FIK-NVCM
See Section 4.11 for information on setting SBUS addresses.
4.6.8 Connecting AC Power
At installation, connect the AC terminals to the power source as shown in Figure 4.39. It may be necessary for a professional electrician to
make this connection.
FIK-125W
FACP
FIK-NVCM
FIK-125W
To Next Page
