2.2.3 PSU SPECIFICATIONS
PSU Part Number:
E10-0067
Transformer Part Number:
02-10644 120/240VAC; 02-10879 100VAC
Transformer Input Power:
100/120/240VAC -15/+10% 50/60Hz , 2A maximum load
Power Consumption:
Calculated with EPWorks™ Software
Input Terminal Block Capacity:
Output Terminal Block Capacity
3.3 to 0.14 mm
2
(12 to 28 AWG)
1.5 to 0.14 mm
2
(16 to 28 AWG)
Input Power:
24VAC at 0.043A no load; 13.0A max load, fused with 15A mini automotive blade type.
L Note: Transformer shall be mounted within 3 meters (10 feet) of PSU using
minimum 2.08mm
2
(14AWG) cabling.
Battery Back-up:
75 AH sealed lead-acid, fused at 15A mini automotive blade type
L Note: Size of sealed, lead-acid batteries required will depend on the number and
type of modules used. The designer shall perform a Power Calculation using the
EPWorks
TM
software or Annex A. Batteries shall be mounted within 3 meters (10
feet) of PSU using minimum 2.08 mm
2
(14AWG) cabling. Batteries require a
VENTED enclosure.
L Note: When replacing batteries use the same size, type and number. Proper
disposal of old batteries is required; refer to local codes.
PSU Output Power:
24VDC at 1A per output circuit fused with 2A mini automotive blade type. Total output
current from all output circuits 5 Amp max. for CSA approval.
PSU Relay Output:
One SPDT Form C for Trouble
Rated DC operation: 2 amps @ 30VDC (pf=.35)
AC operation: 0.5 amps @ 250VAC (pf=.35)
Status Bus:
Belden 9841 or RE-Y2Y cabling recommended. Maximum resistance: R=50 ohms,
inductance L=100uH, capacitance C=0.02uF, maximum length 300 m (1,000 ft) total.
Temperature Rating:
-20°C to 60°C (0°F to 140°F)
Humidity:
80% relative, maximum (non-condensing)
Size:
210 mm L x 130 mm H x 70 mm D (8.2” L x 5.2” H x 2.9” D)
Weight:
1 kg (2 lbs.)
Hazardous Area:
The PSU is not rated for hazardous atmospheres.
For FM or ATEX installations the PSU must be located in a non-hazardous atmosphere.
Current Firmware Version:
Can be verified using EPWorks™ Software.
