ANNUNCIATOR MODULE DISPLAY HISTORY CODES
001 EPC #1 Not Connected x02 EPC #x Trouble on Input Circuit
002 EPC #2 Not Connected x03 EPC #x Pressure Warning Level Exceeded
003 EPC #3 Not Connected x04 EPC #x Trouble on Output Circuit
004 EPC #4 Not Connected x05 EPC #x Trouble on Fire Bus
005 RC8 #5 Not Connected x06 EPC #x Predischarge Condition Satisfied
006 RC8 #6 Not Connected x07 EPC #x Supervisory Input Active
007 RC8 #7 Not Connected x08 EPC #x Activated Releasing Outputs
008 RC8 #8 Not Connected x09 EPC #x Disabled
009 PSU Not Connected x10 EPC # x Failure during Arming
011 EPC #1 Connected 502 RC8 #5 Relay Status
012 EPC #2 Connected 602 RC8 #6 Relay Status
013 EPC #3 Connected 702 RC8 #7 Relay Status
014 EPC #4 Connected 802 RC8 #8 Relay Status
015 RC8 #1 Connected 901 PSU Normal Operation
016 RC8 #2 Connected 902 PSU Fan Trouble
017 RC8 #3 Connected 903 PSU Ground Fault
018 RC8 #4 Connected 904 PSU Battery or Charge Trouble
019 PSU Connected 905 PSU AC Trouble
01A AM Power Up 906 PSU Battery Backup Being Utilized
01B AM Power Off 907 PSU Output Trouble
01C AM Serviced by Engineer 908 PSU Outputs Disabled
x01 EPC #x Normal Operation 909 PSU Auto Shutdown Mode
“x” = EPC 1 through 4
