EPACO USER’S MANUAL
Release Date: January, 2010 P/N: E06-091 (Rev 0) Page: 19
APPENDIX A
RC8 MODULE STATUS CODES
Digit Number STATUS OF RELAY
Designates
Module
Designates Status of
Selected Module
WITH CODE AT LEFT
DISPLAYED ON ANNUNCIATOR MODULE
5-8 = RC8 2 3 1 2 3 4 5 6 7 8
5 WRITE IN
6 STATE
7 PROGRAMMED
8 TO RIGHT
X - - No RC8 or No Communications
X 0 0 OFF OFF OFF OFF OFF OFF OFF OFF
X 0 1 ON OFF OFF OFF OFF OFF OFF OFF
X 0 2 OFF ON OFF OFF OFF OFF OFF OFF
X 0 3 ON ON OFF OFF OFF OFF OFF OFF
X 0 4 OFF OFF ON OFF OFF OFF OFF OFF
X 0 5 ON OFF ON OFF OFF OFF OFF OFF
X 0 6 OFF ON ON OFF OFF OFF OFF OFF
X 0 7 ON ON ON OFF OFF OFF OFF OFF
X 0 8 OFF OFF OFF ON OFF OFF OFF OFF
X 0 9 ON OFF OFF ON OFF OFF OFF OFF
X 0 A OFF ON OFF ON OFF OFF OFF OFF
X 0 B ON ON OFF ON OFF OFF OFF OFF
X 0 C OFF OFF ON ON OFF OFF OFF OFF
X 0 D ON OFF ON ON OFF OFF OFF OFF
X 0 E OFF ON ON ON OFF OFF OFF OFF
X 0 F ON ON ON ON OFF OFF OFF OFF
X 1 0 OFF OFF OFF OFF ON OFF OFF OFF
X 1 1 ON OFF OFF OFF ON OFF OFF OFF
X 1 2 OFF ON OFF OFF ON OFF OFF OFF
X 1 3 ON ON OFF OFF ON OFF OFF OFF
X 1 4 OFF OFF ON OFF ON OFF OFF OFF
X 1 5 ON OFF ON OFF ON OFF OFF OFF
X 1 6 OFF ON ON OFF ON OFF OFF OFF
X 1 7 ON ON ON OFF ON OFF OFF OFF
X 1 8 OFF OFF OFF ON ON OFF OFF OFF
X 1 9 ON OFF OFF ON ON OFF OFF OFF
X 1 A OFF ON OFF ON ON OFF OFF OFF
X 1 B ON ON OFF ON ON OFF OFF OFF
X 1 C OFF OFF ON ON ON OFF OFF OFF
X 1 D ON OFF ON ON ON OFF OFF OFF
X 1 E OFF ON ON ON ON OFF OFF OFF
X 1 F ON ON ON ON ON OFF OFF OFF
X 2 0 OFF OFF OFF OFF OFF ON OFF OFF
X 2 1 ON OFF OFF OFF OFF ON OFF OFF
X 2 2 OFF ON OFF OFF OFF ON OFF OFF
X 2 3 ON ON OFF OFF OFF ON OFF OFF
X 2 4 OFF OFF ON OFF OFF ON OFF OFF
X 2 5 ON OFF ON OFF OFF ON OFF OFF
X 2 6 OFF ON ON OFF OFF ON OFF OFF
X 2 7 ON ON ON OFF OFF ON OFF OFF
X 2 8 OFF OFF OFF ON OFF ON OFF OFF
X 2 9 ON OFF OFF ON OFF ON OFF OFF
X 2 A OFF ON OFF ON OFF ON OFF OFF
X 2 B ON ON OFF ON OFF ON OFF OFF
X 2 C OFF OFF ON ON OFF ON OFF OFF
X 2 D ON OFF ON ON OFF ON OFF OFF
X 2 E OFF ON ON ON OFF ON OFF OFF
X 2 F ON ON ON ON OFF ON OFF OFF
X 3 0 OFF OFF OFF OFF ON ON OFF OFF
X 3 1 ON OFF OFF OFF ON ON OFF OFF
X 3 2 OFF ON OFF OFF ON ON OFF OFF
X 3 3 ON ON OFF OFF ON ON OFF OFF
To Next Page
