EPACO USER’S MANUAL
Release Date: January, 2010 P/N: E06-091 (Rev 0) Page: 11
2.2.4 PSU VOLTAGE CHART
MINIMUM TYPICAL MAXIMUM
AC Power Input
100V Transformer 85V 100V 110V
120V Transformer 102V 120V 132V
240V Transformer 204V 240V 264V
25VAC (P3) 21V 25V 30V
Battery Charge Power
Charge, P4 (V) 24V 27.6V 29V
Battery Backup
Battery Range 18V 27V 29.5V
Low Battery Trouble 24V
Battery Shut-down 18V
Battery Disconnect 17V
Output Power (single out)
Out (V) 18V 24V 30V
Out (A) 1A 2A
Output Power Overall
6A
