EPACO USER’S MANUAL
Release Date: January, 2010 P/N: E06-091 (Rev 0) Page: 25
APPENDIX C
PRESSURE DETECTOR - PRESSURE CORRELATION CHART
Hexadecimal
Display
(Digits 2 & 3)
Pressure at
Detector
(PSI)
Pressure at
Detector
(mbar)
Hexadecimal
Display
(Digits 2 & 3)
Pressure at
Detector
(PSI)
Pressure at
Detector
(mbar)
Hexadecimal
Display
(Digits 2 & 3)
Pressure at
Detector
(PSI)
Pressure at
Detector
(mbar)
00 -5.23 -361 30 -2.80 -193 60 -1.07 -74
01 -5.18 -357 31 -2.77 -191 61 -1.03 -71
02 -5.07 -349 32 -2.74 -189 62 -1.00 -69
03 -4.95 -341 33 -2.69 -185 63 -0.96 -66
04 -4.85 -334 34 -2.65 -183 64 -0.92 -64
05 -4.77 -329 35 -2.62 -180 65 -0.89 -61
06 -4.70 -324 36 -2.58 -178 66 -0.86 -59
07 -4.63 -319 37 -2.54 -175 67 -0.82 -57
08 -4.56 -315 38 -2.52 -173 68 -0.79 -54
09 -4.50 -310 39 -2.48 -171 69 -0.75 -52
0A -4.44 -306 3A -2.43 -167 6A -0.72 -49
0B -4.39 -303 3B -2.39 -165 6B -0.68 -47
0C -4.34 -299 3C -2.36 -162 6C -0.65 -45
0D -4.28 -295 3D -2.32 -160 6D -0.61 -42
0E -4.23 -292 3E -2.28 -157 6E -0.58 -40
0F -4.18 -288 3F -2.25 -155 6F -0.55 -38
10 -4.13 -285 40 -2.21 -152 70 -0.51 -35
11 -4.08 -281 41 -2.17 -150 71 -0.47 -33
12 -4.04 -278 42 -2.13 -147 72 -0.44 -30
13 -4.00 -275 43 -2.10 -145 73 -0.40 -28
14 -3.94 -272 44 -2.06 -142 74 -0.37 -25
15 -3.90 -269 45 -2.03 -140 75 -0.34 -23
16 -3.86 -266 46 -1.99 -137 76 -0.31 -21
17 -3.81 -263 47 -1.96 -135 77 -0.27 -19
18 -3.77 -260 48 -1.92 -132 78 -0.23 -16
19 -3.72 -257 49 -1.88 -130 79 -0.20 -14
1A -3.68 -254 4A -1.85 -127 7A -0.16 -11
1B -3.64 -251 4B -1.81 -125 7B -0.13 -9
1C -3.60 -248 4C -1.77 -122 7C -0.10 -7
1D -3.56 -245 4D -1.74 -120 7D -0.06 -4
1E -3.52 -242 4E -1.71 -118 7E -0.03 -2
1F -3.47 -239 4F -1.67 -115 7F 0.00 0
20 -3.43 -237 50 -1.63 -112 80 0.03 2
21 -3.39 -234 51 -1.59 -110 81 0.07 4
22 -3.35 -231 52 -1.56 -107 82 0.10 7
23 -3.31 -228 53 -1.52 -105 83 0.13 9
24 -3.26 -225 54 -1.49 -102 84 0.17 12
25 -3.22 -222 55 -1.45 -100 85 0.21 14
26 -3.18 -220 56 -1.42 -98 86 0.24 17
27 -3.14 -217 57 -1.39 -95 87 0.28 19
28 -3.10 -214 58 -1.35 -93 88 0.31 22
29 -3.06 -211 59 -1.31 -90 89 0.35 24
2A -3.02 -208 5A -1.28 -88 8A 0.38 26
2B -2.99 -206 5B -1.24 -86 8B 0.41 28
2C -2.95 -203 5C -1.21 -83 8C 0.45 31
2D -2.91 -201 5D -1.17 -81 8D 0.49 33
2E -2.88 -198 5E -1.14 -78 8E 0.52 36
2F -2.84 -196 5F -1.10 -76 8F 0.55 38
