EPACO USER’S MANUAL
Page: 14 P/N E06-091 (Rev 0) Release Date: January, 2010
2.3.2 AM SPECIFICATIONS
Part Number:
E10-0068
Input Power:
18 to 30 VDC; 300mA
Max. Noise Ripple:
500mV peak at 24 VDC
Fuse:
2A Mini Automotive Type
Lower Limit for Input Power
Shut-down:
16 VDC
Power Consumption:
130mA in Normal State
Terminal Block Capacity:
1.5 to 0.14 mm
2
(16 to 28 AWG)
Relay Output:
One SPDT Form C for Trouble; One SPDT Form C for Alarm.
Both rated: DC operation: 2 amps @ 30VDC (pf=0.35)
AC operation: 0.5 amps @ 250VAC (pf=0.35)
Status Bus:
Wire specification Alpha wire or RE-Y2Y or Belden 9841, maximum resistance of 50 Ω,
inductance L=100uH, capacitance C=0.02uF, maximum length 300 m (1,000 ft) total.
Remote Bus:
Wire specification Alpha wire or RE-Y2Y or Belden 9841, maximum resistance of 50 Ω,
inductance L=100uH, capacitance C=0.02uF, maximum length 300 m (1,000 ft) total.
Temperature Rating:
-18°C to 60°C (0°F to 140°F). If AM is not located inside auxiliary housing, maximum
temperature is 43.3°C (110°F).
Humidity:
80% relative, maximum (non-condensing).
Size:
120 mm L x 130 mm H x 60 mm D (4.8” L x 5.2” H x 2.3” D).
Weight:
0.5 kg (1 lbs.).
Hazardous Area:
The AM is not rated for hazardous atmospheres.
For FM or ATEX installations the AM must be located in a non-hazardous atmosphere.
Current Firmware Version:
Can be verified using EPWorks™ Software.
