Fike Epaco - Appendix B; Annunciator Module Display History Codes

EPACO USER’S MANUAL
Page: 20 P/N E06-091 (Rev 0) Release Date: January, 2010
Digit Number STATUS OF RELAY
Designates
Module
Designates Status of
Selected Module
WITH CODE AT LEFT
DISPLAYED ON ANNUNCIATOR MODULE
5-8 = RC8 2 3 1 2 3 4 5 6 7 8
X 3 4 OFF OFF ON OFF ON ON OFF OFF
X 3 5 ON OFF ON OFF ON ON OFF OFF
X 3 6 OFF ON ON OFF ON ON OFF OFF
X 3 7 ON ON ON OFF ON ON OFF OFF
X 3 8 OFF OFF OFF ON ON ON OFF OFF
X 3 9 ON OFF OFF ON ON ON OFF OFF
X 3 A OFF ON OFF ON ON ON OFF OFF
X 3 B ON ON OFF ON ON ON OFF OFF
X 3 C OFF OFF ON ON ON ON OFF OFF
X 3 D ON OFF ON ON ON ON OFF OFF
X 3 E OFF ON ON ON ON ON OFF OFF
X 3 F ON ON ON ON ON ON OFF OFF
X 4 0 OFF OFF OFF OFF OFF OFF ON OFF
X 4 1 ON OFF OFF OFF OFF OFF ON OFF
X 4 2 OFF ON OFF OFF OFF OFF ON OFF
X 4 3 ON ON OFF OFF OFF OFF ON OFF
X 4 4 OFF OFF ON OFF OFF OFF ON OFF
X 4 5 ON OFF ON OFF OFF OFF ON OFF
X 4 6 OFF ON ON OFF OFF OFF ON OFF
X 4 7 ON ON ON OFF OFF OFF ON OFF
X 4 8 OFF OFF OFF ON OFF OFF ON OFF
X 4 9 ON OFF OFF ON OFF OFF ON OFF
X 4 A OFF ON OFF ON OFF OFF ON OFF
X 4 B ON ON OFF ON OFF OFF ON OFF
X 4 C OFF OFF ON ON OFF OFF ON OFF
X 4 D ON OFF ON ON OFF OFF ON OFF
X 4 E OFF ON ON ON OFF OFF ON OFF
X 4 F ON ON ON ON OFF OFF ON OFF
X 5 0 OFF OFF OFF OFF ON OFF ON OFF
X 5 1 ON OFF OFF OFF ON OFF ON OFF
X 5 2 OFF ON OFF OFF ON OFF ON OFF
X 5 3 ON ON OFF OFF ON OFF ON OFF
X 5 4 OFF OFF ON OFF ON OFF ON OFF
X 5 5 ON OFF ON OFF ON OFF ON OFF
X 5 6 OFF ON ON OFF ON OFF ON OFF
X 5 7 ON ON ON OFF ON OFF ON OFF
X 5 8 OFF OFF OFF ON ON OFF ON OFF
X 5 9 ON OFF OFF ON ON OFF ON OFF
X 5 A OFF ON OFF ON ON OFF ON OFF
X 5 B ON ON OFF ON ON OFF ON OFF
X 5 C OFF OFF ON ON ON OFF ON OFF
X 5 D ON OFF ON ON ON OFF ON OFF
X 5 E OFF ON ON ON ON OFF ON OFF
X 5 F ON ON ON ON ON OFF ON OFF
X 6 0 OFF OFF OFF OFF OFF ON ON OFF
X 6 1 ON OFF OFF OFF OFF ON ON OFF
X 6 2 OFF ON OFF OFF OFF ON ON OFF
X 6 3 ON ON OFF OFF OFF ON ON OFF
X 6 4 OFF OFF ON OFF OFF ON ON OFF
X 6 5 ON OFF ON OFF OFF ON ON OFF
X 6 6 OFF ON ON OFF OFF ON ON OFF
X 6 7 ON ON ON OFF OFF ON ON OFF
X 6 8 OFF OFF OFF ON OFF ON ON OFF
X 6 9 ON OFF OFF ON OFF ON ON OFF
X 6 A OFF ON OFF ON OFF ON ON OFF
X 6 B ON ON OFF ON OFF ON ON OFF
X 6 C OFF OFF ON ON OFF ON ON OFF
X 6 D ON OFF ON ON OFF ON ON OFF
X 6 E OFF ON ON ON OFF ON ON OFF
X 6 F ON ON ON ON OFF ON ON OFF
