Fike Epaco - Appendix C; Pressure Detector - Pressure Correlation Chart

EPACO USER’S MANUAL
Release Date: January, 2010 P/N: E06-091 (Rev 0) Page: 21
Digit Number STATUS OF RELAY
Designates
Module
Designates Status of
Selected Module
WITH CODE AT LEFT
DISPLAYED ON ANNUNCIATOR MODULE
5-8 = RC8 2 3 1 2 3 4 5 6 7 8
X 7 0 OFF OFF OFF OFF ON ON ON OFF
X 7 1 ON OFF OFF OFF ON ON ON OFF
X 7 2 OFF ON OFF OFF ON ON ON OFF
X 7 3 ON ON OFF OFF ON ON ON OFF
X 7 4 OFF OFF ON OFF ON ON ON OFF
X 7 5 ON OFF ON OFF ON ON ON OFF
X 7 6 OFF ON ON OFF ON ON ON OFF
X 7 7 ON ON ON OFF ON ON ON OFF
X 7 8 OFF OFF OFF ON ON ON ON OFF
X 7 9 ON OFF OFF ON ON ON ON OFF
X 7 A OFF ON OFF ON ON ON ON OFF
X 7 B ON ON OFF ON ON ON ON OFF
X 7 C OFF OFF ON ON ON ON ON OFF
X 7 D ON OFF ON ON ON ON ON OFF
X 7 E OFF ON ON ON ON ON ON OFF
X 7 F ON ON ON ON ON ON ON OFF
X 8 0 OFF OFF OFF OFF OFF OFF OFF ON
X 8 1 ON OFF OFF OFF OFF OFF OFF ON
X 8 2 OFF ON OFF OFF OFF OFF OFF ON
X 8 3 ON ON OFF OFF OFF OFF OFF ON
X 8 4 OFF OFF ON OFF OFF OFF OFF ON
X 8 5 ON OFF ON OFF OFF OFF OFF ON
X 8 6 OFF ON ON OFF OFF OFF OFF ON
X 8 7 ON ON ON OFF OFF OFF OFF ON
X 8 8 OFF OFF OFF ON OFF OFF OFF ON
X 8 9 ON OFF OFF ON OFF OFF OFF ON
X 8 A OFF ON OFF ON OFF OFF OFF ON
X 8 B ON ON OFF ON OFF OFF OFF ON
X 8 C OFF OFF ON ON OFF OFF OFF ON
X 8 D ON OFF ON ON OFF OFF OFF ON
X 8 E OFF ON ON ON OFF OFF OFF ON
X 8 F ON ON ON ON OFF OFF OFF ON
X 9 0 OFF OFF OFF OFF ON OFF OFF ON
X 9 1 ON OFF OFF OFF ON OFF OFF ON
X 9 2 OFF ON OFF OFF ON OFF OFF ON
X 9 3 ON ON OFF OFF ON OFF OFF ON
X 9 4 OFF OFF ON OFF ON OFF OFF ON
X 9 5 ON OFF ON OFF ON OFF OFF ON
X 9 6 OFF ON ON OFF ON OFF OFF ON
X 9 7 ON ON ON OFF ON OFF OFF ON
X 9 8 OFF OFF OFF ON ON OFF OFF ON
X 9 9 ON OFF OFF ON ON OFF OFF ON
X 9 A OFF ON OFF ON ON OFF OFF ON
X 9 B ON ON OFF ON ON OFF OFF ON
X 9 C OFF OFF ON ON ON OFF OFF ON
X 9 D ON OFF ON ON ON OFF OFF ON
X 9 E OFF ON ON ON ON OFF OFF ON
X 9 F ON ON ON ON ON OFF OFF ON
X A 0 OFF OFF OFF OFF OFF ON OFF ON
X A 1 ON OFF OFF OFF OFF ON OFF ON
X A 2 OFF ON OFF OFF OFF ON OFF ON
X A 3 ON ON OFF OFF OFF ON OFF ON
X A 4 OFF OFF ON OFF OFF ON OFF ON
X A 5 ON OFF ON OFF OFF ON OFF ON
X A 6 OFF ON ON OFF OFF ON OFF ON
X A 7 ON ON ON OFF OFF ON OFF ON
X A 8 OFF OFF OFF ON OFF ON OFF ON
X A 9 ON OFF OFF ON OFF ON OFF ON
X A A OFF ON OFF ON OFF ON OFF ON
X A B ON ON OFF ON OFF ON OFF ON
