EPACO USER’S MANUAL
Release Date: January, 2010 P/N: E06-091 (Rev 0) Page: 23
Digit Number STATUS OF RELAY
Designates
Module
Designates Status of
Selected Module
WITH CODE AT LEFT
DISPLAYED ON ANNUNCIATOR MODULE
5-8 = RC8 2 3 1 2 3 4 5 6 7 8
X E 8 OFF OFF OFF ON OFF ON ON ON
X E 9 ON OFF OFF ON OFF ON ON ON
X E A OFF ON OFF ON OFF ON ON ON
X E B ON ON OFF ON OFF ON ON ON
X E C OFF OFF ON ON OFF ON ON ON
X E D ON OFF ON ON OFF ON ON ON
X E E OFF ON ON ON OFF ON ON ON
X E F ON ON ON ON OFF ON ON ON
X F 0 OFF OFF OFF OFF ON ON ON ON
X F 1 ON OFF OFF OFF ON ON ON ON
X F 2 OFF ON OFF OFF ON ON ON ON
X F 3 ON ON OFF OFF ON ON ON ON
X F 4 OFF OFF ON OFF ON ON ON ON
X F 5 ON OFF ON OFF ON ON ON ON
X F 6 OFF ON ON OFF ON ON ON ON
X F 7 ON ON ON OFF ON ON ON ON
X F 8 OFF OFF OFF ON ON ON ON ON
X F 9 ON OFF OFF ON ON ON ON ON
X F A OFF ON OFF ON ON ON ON ON
X F B ON ON OFF ON ON ON ON ON
X F C OFF OFF ON ON ON ON ON ON
X F D ON OFF ON ON ON ON ON ON
X F E OFF ON ON ON ON ON ON ON
X F F ON ON ON ON ON ON ON ON
Example Status Displays:
“500” – The first RC8, #5, has all relays OFF.
“7A2” – The third RC8, #7, has Relay 1 OFF; Relay2 ON; Relay 3 OFF; Relay 4 OFF; Relay 5 OFF;
Relay 6 ON; Relay 7 OFF; Relay 8 ON
X A 2 OFF ON OFF OFF OFF ON OFF ON
“813” – The fourth RC8, #8, has Relay 1 ON; Relay 2 ON; Relay 3 OFF; Relay 4 OFF; Relay 5 ON;
Relay 6 OFF; Relay 7 OFF; Relay 8 OFF
X 1 3 ON ON OFF OFF ON OFF OFF OFF
Note: Specific trouble types per module can be accessed via the Fike EP Works
TM
software.
